40 KHz ~ 160 KHz (視清洗物決定何種頻率,並非頻率可調)
40KHz ~ 160KHz ( Depending on what kind of frequency cleaning, not frequency adjustable)
| Model / 機型 | DC100 / DC100H | DC150 / DC150H | DC200 / DC200H DC300 / DC300H | DC400 / DC400H DC600-30 / DC600H-30 | DC600-45 / DC600H-45 DC900 / DC900H |
 |  |  |  |  | |
| Tank size /水槽尺寸 | 300×160×100 mm (L×W×H) | 300×160×150 mm (L×W×H) | 300×240×150 mm (L×W×H) | 500×300×200 mm (L×W×H) | 500×300×300 mm (L×W×H) |
| Ext. size / 外部尺寸 | 330×205×280 mm (L×W×H) | 330×205×330 mm (L×W×H) | 330×285×330 mm (L×W×H) | 530×345×380 mm (L×W×H) | 530×345×480 mm (L×W×H) |
| Capacity / 水槽容積 | 4.8 L | 7.2 L | 10.8 L | 30 L | 45 L |
| Frequency / 振盪頻率 | 40 KHz | 40 KHz | 40 KHz | 40 KHz | 40 KHz |
| Tank material / 水槽材質 | SUS304 # 1.2 mm | SUS304 # 1.5 mm | SUS304 # 1.5 mm | SUS304 # 1.5 mm | SUS304 # 1.5 mm |
| Ext. material /外部材質 | SUS304 # 0.8 mm | SUS304 # 0.8 mm | SUS304 # 0.8 mm | SUS304 # 0.8 mm | SUS304 # 0.8 mm |
| Cover material /上蓋材質 | SUS304 | SUS304 | SUS304 | SUS304 | SUS304 |
| Output power / 洗淨出力 | 100 W | 150 W | 200 W / 300 W | 400 W / 600 W | 600 W / 900 W |
| Timer / 計時器 | Continuous ” 0 ” & 99min. | Continuous ” 0 ” & 99min. | Continuous ” 0 ” & 99min. | Continuous ” 0 ” & 99min. | Continuous ” 0 ” & 99min. |
| Heater / 加熱器 | 150 W (DC100H) | 250 W (DC150H) | 250 W (DC200H & DC300H) | 500 W (DC400H & DC600H) | 1000 W (DC600H & DC900H) |
| Temp. setting / 溫度設定 | Highest 80°C(DC100H) | Highest 99°C (DC150H) | Highest 99°C (DC200H & DC300H) | Highest 99°C (DC400H & DC600H) | Highest 99°C (DC600H & DC900H) |
| Basket size / 洗籃尺寸 | 280×135×60 mm (L×W×H) | 280×130×100 mm (L×W×H) | 260×220×100 mm (L×W×H) | 445×270×135 mm (L×W×H) | 435×270×135 mm (L×W×H) |
| Net weight / 淨重 | 5 Kg | 8 Kg | 9.5 kg / 10.5 kg | 18.5 kg / 19.5 kg | 22 kg / 24 kg |
| Power supply / 使用電源 | AC100 ~ 120V / 60Hz or AC220 ~ 240V / 50Hz 1Φ | ||||
