Application:
EtBr Gel , SYBR Green Gel , SYPRO Orange Gel , SYPRO Red Gel ,
SYPRO Ruby Gel , Commasie blue Gel , X-ray film , Colony plate ,
Western blot , TLC plate , Realtime electrophoresis , chemiluminescence
Specification:
1. 1/2inch, grayscale, Cool CCD -25 ℃ ( bellow ambient ), high sensitive detecting system.
sensitivity <0.01ng
2. Chip resolution :1391×1039=1,440,000pixels, ( Max.5,700,000)
3. Preview resolution:1391×1039.
4. Exposure time : 0.001 second – 10 hours.
5. Filter selector: 4 filter well, rotating change, include insert hole which is easily to access and
install filters in this full dark box.
6. Quantitative depth: 16bit , grayscale = 65535.
7. Filter : Standard include EtBr filter( wavelength= 595nm ), Option: other wavelength /
440nm, 530nm, 630nm
8. Setting sequence capture: automatic catch 1-10 images with different exposure time and auto save.
9. Zoom Lens: 8-48mm / F1.2, ( Option: 8-48mm / F1.0 )
10. White light source: reflective, 8WX2 tubes, Option : other wavelength light source UVA, UVB, UVC
11. Safety door can automatic shot down the UV Light when door is open or continuous lighting on for
view actual gel or cutting gel
12. Option: can install multi-wavelength light source ( 440nm , 530nm, 590nm , 630nm. Etc.) and
flexible light source for Realtime electrophoresis or Multi-color fluorescent images .
