SPLInsert™ products closely mimic in vivo environment, providing improved attachment, growth and differentiation of various cell types. With their permeable property, inserts are convenient and effective tool for diverse research areas such as transportation and invasion studies. Specially selected track-etched membranes of three different pore sizes (0.4, 3.0 and 8.0 μm) are used for SPLInsert™ products. Track-etched membranes ensure precise pore size distribution and consistent pore density, providing well-controlled experimental parameters.
Polycarbonate (PC): stain-free, low background interference
Polyethylene terephthalate (PET): high chemical resistance and low protein binding property
Applicable experiments: invasion, migration, transportation, drug uptake, epithelial polarization, chemotaxis, co-culture, toxicity study and in vivo barrier modeling
| Cat. No. | Type | Membrane Material | Membrane Pore Size (μm) | Membrane Diameter (mm) | Growth Area (cm²) | Working Volume (ml) | Optical Properties | Sterile | Packaging |
|---|---|---|---|---|---|---|---|---|---|
| 35006 | 6 Inserts / 6well Plate | PC | 0.40 | 24.00 | 4.52 | 1.50 ~ 2.50 | Opaque | + | 6 Inserts / Plate 4 Plates / Box |
| 35106 | 6 Inserts / 6well Plate | PC | 3.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 Inserts / Plate 4 Plates / Box |
| 35206 | 6 Inserts / 6well Plate | PC | 8.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 Inserts / Plate 4 Plates / Box |
| 35012 | 12 Inserts / 12well Plate | PC | 0.40 | 10.50 | 0.90 | 0.40 ~ 1.00 | Opaque | + | 12 Inserts / Plate 4 Plates / Box |
| 35112 | 12 Inserts / 12well Plate | PC | 3.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 35212 | 12 Inserts / 12well Plate | PC | 8.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 35024 | 12 Inserts / 24well Plate | PC | 0.40 | 6.50 | 0.33 | 0.20 ~ 0.35 | Opaque | + | 12 Inserts / Plate 4 Plates / Box |
| 35124 | 12 Inserts / 24well Plate | PC | 3.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 35224 | 12 Inserts / 24well plate | PC | 8.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 36006 | 6 Inserts / 6well Plate | PET | 0.40 | 24.00 | 4.52 | 1.50 ~ 2.50 | Opaque | + | 6 Inserts / Plate 4 Plates / Box |
| 36106 | 6 Inserts / 6well Plate | PET | 3.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 Inserts / Plate 4 Plates / Box |
| 36206 | 6 Inserts / 6well Plate | PET | 8.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 Inserts / Plate 4 Plates / Box |
| 36012 | 12 Inserts / 12well Plate | PET | 0.40 | 10.50 | 0.90 | 0.40 ~ 1.00 | Opaque | + | 12 Inserts / Plate 4 Plates / Box |
| 36112 | 12 Inserts / 12well Plate | PET | 3.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 36212 | 12 Inserts / 12well Plate | PET | 8.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 36024 | 12 Inserts / 24well Plate | PET | 0.40 | 6.50 | 0.33 | 0.20 ~ 0.35 | Opaque | + | 12 Inserts / Plate 4 Plates / Box |
| 36124 | 12 Inserts / 24well Plate | PET | 3.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 36224 | 12 Inserts / 24well Plate | PET | 8.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 12 Inserts / Plate 4 Plates / Box |
| 37006 | 6 Inserts / 6well Plate | PET | 0.40 | 24.00 | 4.52 | 1.50 ~ 2.50 | Transparent | + | 6 Inserts / Plate 4 Plates / Box |
| 37106 | 6 Inserts / 6well Plate | PET | 3.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Transparent | + | 6 Inserts / Plate 4 Plates / Box |
| 37206 | 6 Inserts / 6well Plate | PET | 8.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Transparent | + | 6 Inserts / Plate 4 Plates / Box |
| 37012 | 12 Inserts / 12well Plate | PET | 0.40 | 10.50 | 0.90 | 0.40 ~ 1.00 | Transparent | + | 12 Inserts / Plate 4 Plates / Box |
| 37112 | 12 Inserts / 12well Plate | PET | 3.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Transparent | + | 12 Inserts / Plate 4 Plates / Box |
| 37212 | 12 Inserts / 12well Plate | PET | 8.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Transparent | + | 12 Inserts / Plate 4 Plates / Box |
| 37024 | 12 Inserts / 24well Plate | PET | 0.40 | 6.50 | 0.33 | 0.20 ~ 0.35 | Transparent | + | 12 Inserts / Plate 4 Plates / Box |
| 37124 | 12 Inserts / 24well Plate | PET | 3.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Transparent | + | 12 Inserts / Plate 4 Plates / Box |
| 37224 | 12 Inserts / 24well Plate | PET | 8.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Transparent | + | 12 Inserts / Plate 4 Plates / Box |
| Cat. No. | Type | Membrane Material | Membrane Pore Size (μm) | Membrane Diameter (mm) | Growth Area (cm²) | Working Volume (ml) | Optical Properties | Sterile | Packaging |
|---|---|---|---|---|---|---|---|---|---|
| 35606 | For 6well Plate | PC | 0.40 | 24.00 | 4.52 | 1.50 ~ 2.50 | Opaque | + | 6 / 48 |
| 35706 | For 6well Plate | PC | 3.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 / 48 |
| 35806 | For 6well Plate | PC | 8.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 / 48 |
| 36606 | For 6well Plate | PET | 0.40 | 24.00 | 4.52 | 1.50 ~ 2.50 | Opaque | + | 6 / 48 |
| 36706 | For 6well Plate | PET | 3.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 / 48 |
| 36806 | For 6well Plate | PET | 8.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Translucent | + | 6 / 48 |
| 37606 | For 6well Plate | PET | 0.40 | 24.00 | 4.52 | 1.50 ~ 2.50 | Transparent | + | 6 / 48 |
| 37706 | For 6well Plate | PET | 3.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Transparent | + | 6 / 48 |
| 37806 | For 6well Plate | PET | 8.00 | 24.00 | 4.52 | 1.50 ~ 2.50 | Transparent | + | 6 / 48 |
| 35612 | For 12well Plate | PC | 0.40 | 10.50 | 0.90 | 0.40 ~ 1.00 | Opaque | + | 6 / 48 |
| 35712 | For 12well Plate | PC | 3.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 6 / 48 |
| 35812 | For 12well Plate | PC | 8.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 6 / 48 |
| 36612 | For 12well Plate | PET | 0.40 | 10.50 | 0.90 | 0.40 ~ 1.00 | Opaque | + | 6 / 48 |
| 36712 | For 12well Plate | PET | 0.30 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 6 / 48 |
| 36812 | For 12well Plate | PET | 8.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Translucent | + | 6 / 48 |
| 37612 | For 12well Plate | PET | 0.40 | 10.50 | 0.90 | 0.40 ~ 1.00 | Transparent | + | 6 / 48 |
| 37712 | For 12well Plate | PET | 3.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Transparent | + | 6 / 48 |
| 37812 | For 12well Plate | PET | 8.00 | 10.50 | 0.90 | 0.40 ~ 1.00 | Transparent | + | 6 / 48 |
| 35624 | For 24well Plate | PC | 0.40 | 6.50 | 0.33 | 0.20 ~ 0.35 | Opaque | + | 6 / 48 |
| 35724 | For 24well Plate | PC | 3.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 6 / 48 |
| 35824 | For 24well Plate | PC | 8.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 6 / 48 |
| 36624 | For 24well Plate | PET | 0.40 | 6.50 | 0.33 | 0.20 ~ 0.35 | Opaque | + | 6 / 48 |
| 36724 | For 24well Plate | PET | 3.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 6 / 48 |
| 36824 | For 24well Plate | PET | 8.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Translucent | + | 6 / 48 |
| 37624 | For 24well Plate | PET | 0.40 | 6.50 | 0.33 | 0.20 ~ 0.35 | Transparent | + | 6 / 48 |
| 37724 | For 24well Plate | PET | 3.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Transparent | + | 6 / 48 |
| 37824 | For 24well Plate | PET | 8.00 | 6.50 | 0.33 | 0.20 ~ 0.35 | Transparent | + | 6 / 48 |
